DJ080IA-11A 8.0 Inch INNOLUX LCD Panel

Name: DJ080IA-11A 8.0 Inch INNOLUX LCD Panel
Brand: Shenzhen Wu He Tian Cheng Technology Co., Ltd.

Innolux 8 inch tft lcd ips panel DJ080IA-11A with 1280(RGB)x720 WXGA resolution, brightness 750 cd/m². This lcd display's working temperature is -30 ~ +85 (°C) and it's storage temperature is -40 ~ +90 (°C). Based on it's white LED backlight. This model is recommended for industrial and Car use.

High Brightness 8 Inch 1280*720 WXGA LCD Panel Original Innolux 8" TFT LCD IPS Display For Car DJ080IA-11A Support 750nits Sunlight Readable, 40pins LVDS and Wide Temperature Range -30C.

Compatible resistive touch and capacitive touch options are available. Additionally, we provide a matched LCD controller board and LVDS cables.

Products

Parameters of DJ080IA-11A 8.0 Inch INNOLUX LCD Panel

Size(inch)	Resolution	Model	LCM Dimension(mm)	Active Area(mm)	View	Interface	Luminance(cd/m2)	OP(℃)
8	1280*720	DJ080IA-11A	192.8116.9 6.4	176.64*99.36	IPS	LVDS	500	-30~85°C

General Specifications of DJ080IA-11A 8.0 Inch INNOLUX LCD Panel

DJ080IA-11A

Manufacturer	INNOLUX
Model Name	DJ080IA-11A
Screen Size	8 Inch
Pixel Number	1280(RGB)×720 , WXGA
Active Area(mm)	176.64 × 99.36 (H×V)
Outline(mm）	192.8 × 116.9 × 6.4 (H×V×D)
Pixel Pitch(mm)	0.138 × 0.138 (H×V)
Treatment	Anti-Glare
Luminance	750 cd/m² (Typ.)
Contrast Ratio	1000 : 1 (Typ.) (TM)
Viewing Angle	85/85/85/85 (CR≥10) Left / Right/UP /Down
Response time	10/15 (Typ.)(Tr/Td) ms
Display Mode	AAS , Normally black , Transmissive
Color Depth	262K/16.7M , 70% NTSC
Backlight	WLED , 20K hours , without Driver
Net Weight	205h
Touchscreen	without
Signal Type/interface Type	LVDS (1 ch, 6/8-bit) , 40 pins
Voltage Supply	+3.3 V
Max. Ratings	Storage Temp.: -40 ~ +90 (°C)
Max. Ratings	Operating Temp.: -30 ~ +85 (°C)
Package	Innolux Original package
