G104V1-T03 10.4 Inch INNOLUX LCD Panel

Name: G104V1-T03 10.4 Inch INNOLUX LCD Panel
Brand: Shenzhen Wu He Tian Cheng Technology Co., Ltd.

Innolux 10.4 inch tft lcd ips panel G104V1-T03 with 640(RGB)x480 VGA resolution, brightness 500 cd/m². This lcd display's working temperature is -30 ~ +80 (°C) and it's storage temperature is -30 ~ +80 (°C). Based on it's white LED backlight. This model is recommended for industrial use.

Compatible resistive touch and capacitive touch options are available. Additionally, we provide a matched LCD controller board.

Products

Parameters of G104V1-T03 10.4 Inch INNOLUX LCD Panel

Size(inch)	Resolution	Model	LCM Dimension(mm)	Active Area(mm)	View	Interface	Luminance(cd/m2)	OP(℃)
10.4	640*480	G104V1-T03	225.5176.37.8	211.2*158.4	IPS	CMON/TTL	500	-30~85°C

General Specifications of G104V1-T03 10.4 Inch INNOLUX LCD Panel

G104V1-T03

Manufacturer	Innolux
Model Name	G104V1-T03
Screen Size	10.4 Inch
Pixel Number	640(RGB)×480 , VGA
Active Area(mm)	211.2 × 158.4 (H×V)
Outline(mm）	225.5 × 176.3 × 7.8 (H×V×D)
Pixel Pitch(mm)	215.4 × 161.8 (H×V)
Treatment	Hard coating 3H , Anti-glare (Haze 25%)
Luminance	500 cd/m² (Typ.)
Contrast Ratio	1500 : 1 (Typ.) (TM)
Viewing Angle	88/88/88/88 (CR≥10) Left / Right/UP /Down
Response time	17/9 (Typ.)(Tr/Td) ms
Display Mode	Super MVA , Normally black , Transmissive
Color Depth	262K , 55% NTSC
Backlight	WLED , 50K hours , with LED Driver
Net Weight	445g
Touchscreen	without
Signal Type/interface Type	CMOS/TTL (1 ch, 6-bit) , 31 pins
Voltage Supply	+3.3 V
Max. Ratings	Storage Temp.: -30 ~ +80 (°C)
Max. Ratings	Operating Temp.: -30 ~ +80 (°C)
Package	Innolux Original package;
Package	16 pcs/ctn
