TM050RDH03-41 5.0 Tianma LCD Panel

Name: TM050RDH03-41 5.0 Tianma LCD Panel
Brand: Shenzhen Wu He Tian Cheng Technology Co., Ltd.

TIANMA 5 inch tft lcd panel TM050EDH03-41 with 800x480 WVGA resolution, brightness 250 cd/m².This lcd display is working temperature is -20 ~ +70 (°C) and its storage temperature is -30 ~ +80 (°C).Based on its white LED backlight. This model is recommended for industrial use.

Compatible resistive touch and capacitive touch options are available. Additionally, we provide a matched LCD controller board.

Products

Parameters of TM050RDH03-41 5.0 Tianma LCD Panel

Size(inch)	Resolution	Model	LCM Dimension(mm)	Active Area(mm)	View	Interface	Luminance(cd/m2)	OP(℃)
5	800*480	TM050RDH03-41	120.8075.803.1	108*64.8	TN	RGB	250	-20~70°C
5	800*480	TM050RDZG03-00	120.8075.803.1	108*64.8	TN	RGB	1000	-30~85°C

General Specifications of TM050RDH03-41 5.0 Tianma LCD Panel

Manufacturer	TIANMA
Model Name	TM050RDH03-41
Screen Size	5 inch
Pixel Number	800(RGB)×480, WVGA
Active Area(mm)	108.00 x 64.80 (H×V)
Outline(mm）	120.80 x 75.80 x 3.10 (H×V×D)
Pixel Pitch(mm)	0.135 x 0.135 (H×V)
Treatment	Anti-Glare(3H)
Luminance	250 cd/m² (Typ.)
Contrast Ratio	600 : 1 (Typ.) (TM)
Viewing Angle	70/70/50/70(CR≥10) Left / Right/UP /Down
Response	20 (Typ.)(Tr/Td) ms
Work Mode	TN, Normally white, Transmissive
Color Depth	16.7M , 50% NTSC
Backlight	WLED, 20K hours,without Driver
Net Weight	57.0g
Touchscreen	without
Signal Type/interface Type	Parallel RGB (1 ch, 8-bit) , FPC , 40 pins
Voltage Supply	3.3V
Max. Ratings	Storage Temp.: -30 ~ +80 (°C)
Max. Ratings	Operating Temp.: -20 ~ +70 (°C)
Package	TIANMA Original Package;
	112 pcs/ctn;
	weight : 9.45Kgs;
	size : 530(L)mm x 350(W)mm x 250(H)mm
