INNOLUX offers a diverse range of high-quality LCD panels, featuring various sizes from 3.5 to 23.8 inches, resolutions up to 1920x1080, and advanced IPS technology. These panels provide exceptional luminance, wide operating temperature ranges, and versatile interface options, making them ideal for numerous applications.


Products

Different Types of INNOLUX LCD Panel

INNOLUX offers a diverse range of high-quality LCD panels, featuring various sizes from 3.5 to 23.8 inches, resolutions up to 1920x1080, and advanced IPS technology.

Types of INNOLUX LCD Panel

Size(inch)ResolutionModelLCM Dimension(mm)Active Area(mm)ViewInterfaceLuminance(cd/m2)OP(℃)
3.5320*240LQ35NC11176.9*63.9*3.4670.08*52.56TNRGB300-20~70°C
4.3480*272AT043TN25 V.2105.5*67.2*3.195.04*53.856TNRGB500-20~70°C
4.3480*272AT043TN24 V.7105.5*67.2*3.195.04*53.856TNRGB500-20~70°C
5640*480ZJ050NA-08C117.65*88.43*5.9101.76*76.32TNRGB250-20~70°C
5800*480EJ050NA-01G120.7*76.3*3.3108*64.8TNRGB350-20~70°C
5.6640*480AT056TN53 V.1126.5*100*6112.896*84.672TNRGB500-20~70°C
5.7640*480G057VCE-TH1144*104.6*12.3115.2*86.4TNRGB450-30~85°C
6.5800*480AT065TN14155.2*89.4*5.7143.4*76.704TNRGB400-30~85°C
7800*480LW700AT9309165*104.44*5.7152.4*91.44TNRGB400-20~70°C
7800*480AT070TN83 V.1165*104*5.5152.4*91.44TNRGB300-20~70°C
7800*480AT070TN92164.9*100*5.7154.08*85.92TNRGB250-20~70°C
7800*480AT070TN94164.9*100*5.7154.08*85.92TNRGB400-30~85°C
7800*480G070Y2-L01165*104*9.53152.4*91.44TNLVDS500-30~85°C
7800*480G070ACE-L01170*110*6152.4*91.44IPSLVDS500-30~85°C
7800*480G070ACE-LH1170*110*6152.4*91.44IPSLVDS1000-30~85°C
7800*480G070ACE-LH2170*110*9.35152.4*91.44IPSLVDS500-30~85°C
7800*480G070ACE-LH3165*104*9.53152.4*91.44TNLVDS500-30~85°C
71024*600NJ070NA-23A164.9*100*5.1154.214*85.92TNLVDS500-30~85°C
8800*480AT080TN64192.8*116.9*6.4176.64*99.36TNRGB450-30~85°C
8800*600EJ080NA-05B183*141*5.6162*121.5TNRGB250-30~85°C
81024*600ZJ080NA-08A192.8*116.9*6.7176.64*99.36TNLVDS500-20~70°C
81024*768EJ080NA-04C183*141*3.7162.048*121.536IPSLVDS250-10~50°C
81280*720DJ080IA-11A192.8*116.9* 6.4176.64*99.36IPSLVDS500-30~85°C
9800*480AT090TN12 V.3211.1*126.5*5.9198*111.696TNRGB250-20~70°C
10.11280*800EJ101IA-01G229.46*149.1*2.5216.96*135.6IPSLVDS500-20~70°C
10.11280*800G101ICE-LH1230.7*152.55* 6.5216.96*135.6IPSLVDS500-30~85°C
10.11280*800NJ101IA-01S229.46*149.1*7.7216.96*135.6IPSLVDS650-20~70°C
10.2800*480AT102TN03 V.8235.0*145.8*6.1222.00*132.48TNRGB350-30~85°C
10.2800*480AT102TN03 V.9235.0*145.8*6.1222.00*132.48TNRGB250-30~85°C
10.41024*768G104XCE-LH1225.5*176.5*8.7210.4*157.8IPSLVDS1000-30~85°C
10.4640*480G104V1-T03225.5*176.3*7.8211.2*158.4IPSCMON/TTL500-30~85°C
10.41024*768G104X1-L04225.5*176.8*8.7210.4*157.8IPSLVDS500-30~85°C
10.41024*768G104XCE-LM1238.6*175.8*7.97210.432*157.824IPSLVDS350-20~70°C
10.4800*600G104AGE-L02243*184*8211.2*158.4IPSLVDS400-30~85°C
10.4960*1280G104ACJ-L01225.5*176.5*8.7210.4*157.8IPSLVDS900-30~85°C
10.41024*768G104XCE-L01225.5*176.3*8.7210.4*157.8IPSLVDS500-30~85°C
10.4800*600G104ACE-LH1243*184*8.5211.2*158.4IPSLVDS400-30~85°C
12.11024*768G121XCE-L01260.5*204*8.4245.76*184.32IPSLVDS600-30~85°C
12.11024*768G121XCE-L02260.5*204*8.4245.76*184.32IPSLVDS600-30~85°C
12.1800*600G121ACE-LH1260.5*204*8.4246*184.5IPSLVDS450-30~85°C
12.1800*600G121ACE-LH2260.5*204*8.4246*184.5IPSLVDS450-30~85°C
12.11280*800G121ICE-L01278*184*10261.12*163.2IPSLVDS600-30~85°C
12.31920*720DJ123IC-02A299*120*13.7292.032*109.512IPSLVDS1000-30~85°C
151024*768G150XJE-E01326.5*253.5*9.1304.1*228.1IPSEDP400-30~85°C
151024*768G150XNE-L01326.5*253.5*9.1304.1*228.1IPSLVDS400-30~85°C
151024*768G150XNE-L02326.5*253.5*9.1304.1*228.1IPSLVDS350-30~85°C
151024*768G150XNE-L03326.5*253.5*9.1304.1*228.1IPSLVDS300-30~85°C
151024*768G150XGE-L04326.5*253.5*11.5304.1*228.1IPSLVDS400-30~85°C
15.61920*1080G156HCE-L01363.8*215.98*9.6344.16*193.59IPSLVDS450-30~85°C
15.61920*1080G156HCE-LN1363.8*215.98*9.6344.16*193.59IPSLVDS350-20~70°C
15.61920*1080G156HCE-LH1363.8*215.98*12.7344.16*193.59IPSLVDS1200-20~70°C
15.61366*768G156BGE-L01363.8*215.92*16.85344.232*193.536IPSLVDS300-20~70°C
15.61366*768G156BGE-L03363.8*215.98*9.3344.232*193.536IPSLVDS500-20~70°C
15.61920*1080G156HCE-E01352.14*209.18*6.5344.16*193.59IPSEDP450-30~85°C
18.51366*768G185BGE-L014430.37*254.6*16.1408.9*230.4IPSLVDS300-30~85°C
19.51920*1080G200HJJ-L01459*263*12.47434.88*238.68IPSLVDS450-0~50°C
21.31600*1200R213UCE-L01457*350*19.29432*324IPSLVDS500-0~50°C
21.31600*1200R213UCE-L02457*350*19.29432*324IPSLVDS1000-0~50°C
23.61920*1080M236HJJ-L31544.8*320.5*11521.28*293.22IPSLVDS250-0~50°C
23.81920*1080G238HCJ-L01543*317.4*11.6527.04*296.46IPSLVDS350-0~50°C
23.81920*1080G238HCJ-LH1543*317.4*19.425527.04*296.46IPSLVDS1000-0~50°C


What Is the Color Gamut of INNOLUX LCD Panels?

What Is the Color Gamut of INNOLUX LCD Panels?

The color gamut of INNOLUX LCD panels varies depending on the specific model and technology used. Generally, INNOLUX offers a range of LCD panels with color gamuts that can cover standard sRGB, NTSC, and even DCI-P3 color spaces. For instance, some high-end INNOLUX panels can achieve up to 90% NTSC or 95% DCI-P3, providing vibrant and accurate color reproduction suitable for professional applications. It’s essential to check the specifications of the particular INNOLUX model you are interested in to get precise information about its color gamut capabilities.


INNOLUX LCD Panel FAQs

  • Do INNOLUX LCD panels support 3D display technology?

    Some INNOLUX LCD panels support 3D display technology, offering an immersive viewing experience for compatible content.


  • What is the viewing angle of INNOLUX LCD panels?

    INNOLUX LCD panels typically offer wide viewing angles, up to 178 degrees, ensuring clear visibility from different perspectives.


  • Are INNOLUX LCD panels RoHS compliant?

    Yes, INNOLUX LCD panels comply with RoHS (Restriction of Hazardous Substances) regulations, ensuring they are environmentally friendly.


  • What is the contrast ratio of INNOLUX LCD panels?

    The contrast ratio of INNOLUX LCD panels varies by model but generally ranges from 1000:1 to 5000:1, providing deep blacks and bright whites.
