Tianma LCD Panels design for industrial applications. It features a robust working and storage temperature range, ensuring reliable performance in various environments. The display is equipped with a white LED backlight and offers both resistive and capacitive touch options. Additionally, a compatible LCD controller board is available to enhance its functionality.


Products

Different Types of Tianma LCD Panel

Tianma LCD Panels design for industrial applications. It features a robust working and storage temperature range, ensuring reliable performance in various environments.

Types of Tianma LCD Panel

Size(inch)ResolutionModelLCM Dimension(mm)Active Area(mm)ViewInterfaceLuminance(cd/m2)OP(℃)
3.5320*240TM035KDH03-7976.9*63.9*3.1570.08*52.58TNRGB300-20~70°C
4.3480*272TM043NDHG11105.5*67.2*3.295.04*53.856TNRGB880-20~70°C
5800*480TM050RDH03-41120.80*75.80*3.1108*64.8TNRGB250-20~70°C
5800*480TM050RDZG03-00120.80*75.80*3.1108*64.8TNRGB1000-30~85°C
5.7320*240TM057KDH01-00144*104.60*12.3115.20*86.4TNRGB400-20~70°C
6.5640*480P0650VGF1MA10153*118*11.2132.48*99.36IPSLVDS800-30~80°C
6.5640*480P0650VGF1MA00154*121*11132.48*99.36IPSLVDS1200-30~80°C
7800*480TM070RDHG34-00164.9*100*6154.08*85.92TNRGB1000-30~85°C
71280*800TM070JDHG34-00161*107*6149.76*93.6IPSLVDS600-30~85°C
8800*480P0800WVF1MA00192.0*122.0*10.5174.0*104.4IPSLVDS1000-30~80°C
81024*768TM080TDHG01-00183*141*3.7162.048*121.536IPSLVDS400-20~70°C
8.41024*600P0840XGF1MA00235*143*5.4222.72*125.28IPSLVDS1000-30~85°C
9.71024*768TM097TDHG04-62210.2*166.30*3.28196.61*147.46TNLVDS350-20~70°C
10.11024*600TM101DDHG01-00235*143*5.4222.72*125.28TNLVDS450-20~70°C
10.11280*800TM101JDHP01-00229.46*149.1*4.6216.96*135.6IPSLVDS400-10~50°C
10.11280*800TM101JDHG30-00231.22*150.6*6.6216.96*135.6IPSLVDS500-20~70°C
10.41024*768P1040XGF1MA00230*180.2*9.8210.432*157.824IPSLVDS1300-30~80°C
12.11024*768P1210XGF1MA00260.5*203*10245.76*184.32IPSLVDS1300-30~80°C
12.11024*768TM121TDSG02-00279.0*209*8.6245.76*184.32IPSLVDS450-20~70°C
12.31920*720TM123XDHP90-00311*130*15.7292.32*109.62IPSLVDS1000-30~80°C
151024*768TM150TDSG71328.5*253.5*11.8304.128*228.096IPSLVDS450-20~70°C


What Interfaces Do Tianma LCD Panels Support?

What Interfaces Do Tianma LCD Panels Support?

Tianma LCD panels support a variety of interfaces to cater to different application needs. Common interfaces include MIPI (Mobile Industry Processor Interface), LVDS (Low-Voltage Differential Signaling), and RGB (Red, Green, Blue) for high-speed data transmission and enhanced display quality. Additionally, some panels support HDMI (High-Definition Multimedia Interface) and eDP (Embedded DisplayPort) for more advanced connectivity options. These interfaces ensure compatibility with a wide range of devices, from smartphones and tablets to industrial equipment and automotive displays, making Tianma LCD panels versatile and adaptable to various technological requirements.


Tianma LCD Panels FAQs

  • Are Tianma LCD Panels energy-efficient?

    Yes, Tianma LCD Panels are designed to be energy-efficient, making them suitable for battery-powered devices.


  • What is the typical lifespan of a Tianma LCD Panel?

    The lifespan of a Tianma LCD Panel can vary, but they are generally designed to last for tens of thousands of hours of operation.


  • Do Tianma LCD Panels offer wide viewing angles?

    Many Tianma LCD Panels are designed with wide viewing angles, making them suitable for various applications where visibility from different angles is important.


  • What kind of backlighting do Tianma LCD Panels use?

    Tianma LCD Panels typically use LED backlighting, which provides bright and even illumination.
